The SUTO S215 Dew Point Sensor provides reliable dew point monitoring in industrial applications, with long-term stability and high accuracy over the full range of -20 … +50 °C Td. Along with its compact design, this makes it the ideal solution for compressed air and gas dew point measurements in refrigeration dryers.
Made in Germany. brand SUTO, model S215
Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.
price by request
Available
Official distributor in Latvia
Time-tested American, European and Asian brands of control and measurent instruments
Special price list for organisations
We offer a significant discount for trade organisations and manufacturing companies
Worldwide shipping on request
We take care of all logistics and customs clearance. Fast delivery to Baltic countries
After-sales service and support
Warranty service and repair, expert assistance in the operation of the instruments
The SUTO S215 dew point sensor provides reliable dew point monitoring in industrial applications, offering long‑term stability and high accuracy across the entire range from –20 to +50 °C Td. Thanks to its compact design, it is an ideal solution for measuring the dew point of compressed air and gases in refrigerated dryers.
Plug‑and‑play solutions for compressed air quality monitoring in accordance with ISO 8573‑1. The S215 sensor is available with 2‑wire or 3‑wire 4…20 mA analog outputs, as well as with a Modbus/RTU digital interface. By offering various output signals, users gain high flexibility and seamless integration into any process.
The Modbus/RTU interface allows multiple devices to be connected to a single bus in a daisy‑chain configuration. For example, up to 16 devices can be connected to the SUTO S331 data logger, which represents a powerful and economical solution for data logging and display.
The S215 sensor is also offered with an integrated pressure sensor, combining pressure and dew point measurement in one instrument. An optional OLED display mounted directly on the sensor displays real‑time values at the point of use. The display can be easily rotated by 340° to suit any application (not available for the 2‑wire version).
The SUTO exchange calibration service eliminates downtime and allows users to maintain continuous recording of dew point measurements. The user receives a pre‑calibrated instrument with a calibration certificate and the same settings in advance. After that, the instrument on site is exchanged for the calibrated one and returned to the supplier.
Dew Point Sensor Series Comparison
| Model | S211 | S215 | S220 |
|---|---|---|---|
| Dew point | -60 … +20 °C Td | -20 … +50 °C Td | -100 … +20 °C Td |
| Temperature | -30 … +70 °C | -30 … +70 °C | -30 … +70 °C |
| Pressure | 0 … 1.6 MPa | 0 … 1.6 MPa | 0 … 1.6 MPa |
| Application | In desiccant dryers | In fridge dryers | In high-tech applications |
Features
| MEASUREMENT | |
| Dew Point | |
| Accuracy | ± 1 °C Td (0 … 50 °C Td) ± 2 °C Td (-20 … 0 °C Td) |
| Selectable units | °C, °F, bar(g), MPa(g), psi(g), % rH, g/m³, mg/m³, g/m³ atm., mg/m³ |
| Measuring range | -20 … +50 °C Td |
| Repeatability | 0.25 % from measured value |
| Sensor | Polymer |
| Response time (t90) | 0 °C Td ➞ -20 °C Td ≤ 50 sec -20 °C Td ➞ 0 °C Td ≤ 35 sec @ 4 l/min |
| Pressure | |
| Accuracy | 0.5 % FS |
| Measuring range | 0 … 1.6 MPa |
| Sensor | Piezo-resistiv |
| Temperature | |
| Accuracy | +/- 0.3 °C |
| Measuring range | -30 … +70 °C |
| Sensor | Pt100 |
| Reference conditions | |
| Wählbare Bedingungen | 20 °C 1000 mbar (ISO1217), 0 °C 1013 mbar (DIN1343) Freely adjustable |
| SIGNAL INTERFACE & SUPPLY | |
| Analog output | |
| Signal | 4 … 20 mA 2-wire or 4 … 20 mA 3-wire |
| Scaling | 4 mA = -60; 20 mA = +20 °C Td; freely adjustable |
| Load | 250R |
| Update rate | 3/sec |
| Fieldbus | |
| Protocol | Modbus/RTU |
| Update rate | 1/sec |
| Supply | |
| Voltage supply | 15 … 30 VDC |
| Current consumption | 2-wire: 4 … 20 mA 3-wire: 40 mA @ 24 VDC 3-wire with Display: 50 mA @ 24 VDC |
| GENERAL DATA | |
| Configuration | |
| PC Software | S4C-DP Application |
| Display (Optional) | |
| Integrated | 0.66” OLED display, indicates the measured value and unit |
| Material | |
| Process connection | Stainless steel 1.4301 (SUS 304) |
| Housing | Display cover: PC + ABS |
| Sensor | Polymer + Quartz-Crystal |
| Metal parts | Sinter filter (stainless steel) |
| Miscellaneous | |
| Electrical connection | M12, 5-pole |
| Protection class | IP65 |
| Approvals | CE |
| Process connection | G 1/2” (ISO 228/1) |
| Weight | 180 g |
| Operating conditions | |
| Medium | Air, Argon, O₂, N₂, CO₂* |
| Medium quality | ISO 8573-1: 4.6.3 or better |
| Medium temperature | -30 … +70 °C |
| Medium humidity | ≤ 20 °C Td |
| Operating pressure | 0.1 … 1.6 MPa |
| Ambient temperature | -20 … +70 °C |
| Ambient humidity | 0 … 100 % rH |
| Storage temperature | -20 … +50 °C |
| Transport temperature | -30 … +70 °C |
| Model | Description | Price |
| S699 1215 | S215 Dew Point Transmitter (-20 … +50 °C Td), 2-Wire Analog Output | On request |
| S699 2215 | S215 Dew Point Transmitter (-20 … +50 °C Td), 3-Wire Analog + SDI Output | On request |
| S699 3215 | S215 Dew Point Transmitter (-20 … +50 °C Td), 3-Wire Analog + Modbus/RTU Output | On request |
| S699 4215 | S215 Dew Point Transmitter (-20 … +50 °C Td), integrated Pressure sensor 0 … 1.6 Mpa | On request |
| A1380 | Option: Operating Pressure 0 … 1.6 MPa (Standard) | On request |
| A1387 | Option: OLED Display Option, for 3-wire Analog version (only for S699 2xxx) | On request |
| A1381 | S215/S211: High Pressure 0 … 35.0 MPa (only for S215 & S211) | On request |
| A1388 | Option: OLED Display Option, for 3-wire Analog & Modbus version (only for S699 3xxx & S699 4xxx) | On request |
| A1389 | Option: Without Display (Standard) | On request |
You can request the necessary certificates, documentation, instructions and user guide for SUTO S215 using the special form.
You can buy SUTO S215 in Latvia at a price starting from price by request € in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email olil@olil.lv. SUTO S215 price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
