DWYER VA-K

Photo DWYER VA-K Description DWYER VA-K Specifications DWYER VA-K Ordering DWYER VA-K User Manual for DWYER VA-K Related instruments to DWYER VA-K

DWYER VA-K variable area flowmeter kit

DWYER VA-K variable area flowmeter kit

The Series VA-K Flowmeter Kits offer an economical means of acquiring diverse flow measurement capability. The kit includes a completely assembled flowmeter (available with aluminum or 316 SS end fittings) and three interchangeable 150 mm flow tubes. All flow tubes are supplied with a glass float installed. Spare 316 SS and Tantalum floats are included to extend flow capacities. Series VA-K kits also include a high flow valve cartridge, tripod base, tweezers, pushrod and locking tool for changing floats and flow tubes, correlation charts and plastic carrying case.

			int(6006)
NULL

Made in USA. brand DWYER, model VA-K

Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.

Retailprice from $1071,2

Available

Available

Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.

Advantages

Official distributor in Latvia

Time-tested American, European and Asian brands of control and measurent instruments

Advantages

Special price list for organisations

We offer a significant discount for trade organisations and manufacturing companies

Advantages

Worldwide shipping on request

We take care of all logistics and customs clearance. Fast delivery to Baltic countries

Advantages

After-sales service and support

Warranty service and repair, expert assistance in the operation of the instruments

Description of DWYER VA-K

PRODUCT APPLICATIONS

  • Air and water analysis
  • Film processing
  • Chemical processing
  • Gas chromatography
  • Pharmaceutical
  • Alcohol and tobacco production
  • Pulp and paper
  • Semiconductor industry

Technical specifications of DWYER VA-K

  • Scales: Universal 150 mm scales with correlation chart.
  • Accuracy: ±2% FS @ 70°F (21.1°C) and 14.7 psia (1 atm absolute).
  • Repeatability: ±0.25% of scale reading.
  • Turn-down Ratio: 10:1; 20:1 with combinations of two floats installed in meter.
  • Maximum Operating Pressure: 200 psig (13.8 bar).
  • Maximum Operating Temperature: 250°F (121°C).
  • Mounting: Vertical.
  • Connection: 1/8″ female NPT.
  • Flowtube: Borosilicate glass.
  • Float: Glass, 316 stainless steel or tantalum.
  • Float Stops: PTFE.
  • End Fittings: Anodized Aluminum or 316 stainless steel.
  • Front Shield: Polycarbonate.
  • Side Panels: Black, anodized aluminum.
  • O-rings: Buna-N on aluminum models and fluoroelastomer on stainless steel models.
  • Valve Orifice: Acetal on aluminum models and PCTFE on stainless steel models

How to buy DWYER VA-K

Model Description Price
VA-K1 Aluminum flowmeter kit.
$1,071.20
VA-K2 316 SS flowmeter kit.
$1,240.95
Load More Items

User Guide and Instruction manual for DWYER VA-K

You can request the necessary certificates, documentation, instructions and user guide for DWYER VA-K using the special form.

You can buy DWYER VA-K in Latvia at a price starting from1071,2 $ in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email . DWYER VA-K price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
