DWYER VAT

Photo DWYER VAT Description DWYER VAT Specifications DWYER VAT Ordering DWYER VAT Accessories for DWYER VAT User Manual for DWYER VAT Related instruments to DWYER VAT

DWYER VAT variable area fluoropolymer flowmeter

DWYER VAT variable area fluoropolymer flowmeter

The Series VAT Variable Area Fluoropolymer Flowmeter is ideal for high purity or corrosive liquid applications. This series of flowmeters features a 0 to 10 scale for flow indication. Each unit is individually leak tested to a leak integrity rating of 1 x 10-7 sccs Helium or better.

			int(5944)
NULL

Made in USA. brand DWYER, model VAT

Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.

Retailprice from $582,7

Available

Available

Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.

Advantages

Official distributor in Latvia

Time-tested American, European and Asian brands of control and measurent instruments

Advantages

Special price list for organisations

We offer a significant discount for trade organisations and manufacturing companies

Advantages

Worldwide shipping on request

We take care of all logistics and customs clearance. Fast delivery to Baltic countries

Advantages

After-sales service and support

Warranty service and repair, expert assistance in the operation of the instruments

Description of DWYER VAT

Calibration Option is available in the Accessory tab.

PRODUCT APPLICATIONS

  • Chemical injectors
  • Deionized water systems

FEATURES

  • Chemically inert wetted components yield long life even in corrosive liquid applications
  • All units are individually leak tested for no additional cost

Technical specifications of DWYER VAT

  • Service: Compatible liquids.
  • Wetted Materials: Flowtube: PFA; Float and end fittings: PTFE; Guide rods: PCTFE.
  • Temperature Limits: 250°F (121°C).
  • Pressure Limit: 100 psig (6.9 bar).
  • Accuracy: ±5% FS @ 70°F (21.1°C) and 14.7 psia (1 atm absolute).
  • Process Connections: See model chart on catalog page.
  • Leak Integrity: 1 x 10-7 sccs of Helium.
  • Scale: Direct reading.
  • Mounting: Vertical, in-line.

How to buy DWYER VAT

Model Description Price
VAT-301 Variable area flowmeter, 1/4″ female NPT, flow rate 125 ml/min (1.98 GPH).
$582.70
VAT-302 Variable area flowmeter, 1/4″ female NPT, flow rate 250 ml/min (3.91 GPH).
$582.70
VAT-303 Variable area flowmeter, 1/4″ female NPT, flow rate 400 ml/min (6.34 GPH).
$582.70
VAT-304 Variable area flowmeter, 1/4″ female NPT, flow rate 500 ml/min (7.92 GPH).
$582.70
VAT-305 Variable area flowmeter, 1/4″ female NPT, flow rate 1000 ml/min (15.85 GPH).
$582.70
VAT-306 Variable area flowmeter, 3/8″ female NPT, flow rate 2000 ml/min (31.69 GPH).
$582.70
VAT-307 Variable area flowmeter, 3/8″ female NPT, flow rate 2500 ml/min (39.62 GPH).
$582.70
VAT-308 Variable area flowmeter, 3/8″ female NPT, flow rate 3000 ml/min (47.54 GPH).
$582.70
VAT-309 Variable area flowmeter, 3/8″ female NPT, flow rate 5000 ml/min (79.23 GPH).
$582.70
VAT-311 Variable area flowmeter, 1/4″ female NPT, flow rate 125 ml/min (1.98 GPH).
$992.55
VAT-312 Variable area flowmeter, 1/4″ female NPT, flow rate 250 ml/min (3.91 GPH).
$992.55
VAT-313 Variable area flowmeter, 1/4″ female NPT, flow rate 400 ml/min (6.34 GPH).
$992.55
VAT-314 Variable area flowmeter, 1/4″ female NPT, flow rate 500 ml/min (7.92 GPH).
$992.55
VAT-315 Variable area flowmeter, 1/4″ female NPT, flow rate 1000 ml/min (15.85 GPH).
$992.55
VAT-316 Variable area flowmeter, 3/8″ female NPT, flow rate 2000 ml/min (31.69 GPH).
$992.55
VAT-317 Variable area flowmeter, 3/8″ female NPT, flow rate 2500 ml/min (39.62 GPH).
$992.55
VAT-318 Variable area flowmeter, 3/8″ female NPT, flow rate 3000 ml/min (47.54 GPH).
$992.55
VAT-319 Variable area flowmeter, 3/8″ female NPT, flow rate 5000 ml/min (79.23 GPH).
$992.55
VAT-6010 Variable area flowmeter, 1/2″ female NPT, flow rate 13 LPM (3.43 GPM).
$1,678.75
VAT-6011 Variable area flowmeter, 1/2″ female NPT, flow rate 20 LPM (5.28 GPM).
$1,678.75
VAT-6012 Variable area flowmeter, 3/4″ female NPT, flow rate 30 LPM (7.93 GPM).
$1,678.75
VAT-6013 Variable area flowmeter, 3/4″ female NPT, flow rate 40 LPM (10.57 GPM).
$1,678.75
VAT-6110 Variable area flowmeter, 1/2″ female NPT, flow rate 13 LPM (3.43 GPM).
$2,310.10
VAT-6111 Variable area flowmeter, 1/2″ female NPT, flow rate 20 LPM (5.28 GPM).
$2,310.10
VAT-6112 Variable area flowmeter, 3/4″ female NPT, flow rate 30 LPM (7.93 GPM).
$2,310.10
VAT-6113 Variable area flowmeter, 3/4″ female NPT, flow rate 40 LPM (10.57 GPM).
$2,310.10
VAT-6114 Variable area flowmeter, 3/4″ female NPT, flow rate 45 LPM (11.89 GPM).
$2,310.10
Load More Items

Accessories for DWYER VAT

Model Description Price
NISTCAL-FL2 NIST traceable calibration certificate for variable area flowmeters (water).
NOTE: EQUAL CERTS WILL BE CHARGED PER UNITS PURCHASED.
$292.00
Load More Items

User Guide and Instruction manual for DWYER VAT

You can request the necessary certificates, documentation, instructions and user guide for DWYER VAT using the special form.

You can buy DWYER VAT in Latvia at a price starting from582,7 $ in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email . DWYER VAT price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
