NAGMAN MPC-I-H+ Digital Pressure Indicator

NAGMAN MPC-I-H+ Digital Pressure Indicator
  • Digital Pressure Indicator
  • Silicon Keys
  • Selectable Engineering Pressure Units
  • DC Current & Voltage Measurement
  • Switch Test capability & Zero Offset facility
  • Loop Supply Provided
  • Pressure Transducer – all Media compatible with SS316
  • Low Battery Indication
  • Auto Power Off
  • Rugged Protection Holster
  • USB Interface
			int(6940)
NULL

Made in India. brand NAGMAN, model MPC-I-H+

Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.

price by request

Available

Available

Advantages

Official distributor in Latvia

Time-tested American, European and Asian brands of control and measurent instruments

Advantages

Special price list for organisations

We offer a significant discount for trade organisations and manufacturing companies

Advantages

Worldwide shipping on request

We take care of all logistics and customs clearance. Fast delivery to Baltic countries

Advantages

After-sales service and support

Warranty service and repair, expert assistance in the operation of the instruments

Description of NAGMAN MPC-I-H+

  • Pressure Indicator
  • Test Leads & Seals Kit
  • USB Interface
  • External Charger
  • ‘Calpress’ Calibration Software with Cable
  • Calibration Certificates are issued in Accordance with our Scope as granted by NABL per ISO/IEC 17025:2017 Standards
  • Instruction Manual

Technical specifications of NAGMAN MPC-I-H+

Ideal Lab / Site Tool for checking & Calibration of Hydraulic Pressure / Differential Pressure Gauges / Switches / Transmitters / Receiver Gauges / Loops etc.

  • Range: 0  to 70 / 100 / 200 / 250 / 350 / 700 / 1000 bar
  • Accuracy: ±0.025% F.S.
  • Display Resolution: Minimum 5 digits
  • Display: 7 Segment FSTN (Large) Display
  • Engineering Units (12): Refer Table below
  • mA Input: 0 to 50 mA DC
  • Volt Input: 0 – 10V
  • Resolution for mA & Volt: 0.001
  • Process Connection: ½” BSP (M)
  • Over Pressure Alarm: 105% FS (Audio / Visual)
  • Battery Type : 7.2 Volts Rechargeable Battery
  • Hand Pump + Hose with End Fittings
  • Quick Connector
  • Carrying Case
  • Set of Adaptors

7 Segment Classification of Engineering Units

Range

(bar)

 Pressure / Engineering Units – Resolution
inH2O mH2O cmH2O mmH2O inHg mmHg Mbar kPa Mpa bar Kg/cm2 psi
70 1 0.01 1 — 0.1 1 1 0.1 0.001 0.01 0.01 0.1
100 ~ 200 1 0.1 — — 0.1 1 — 1 0.001 0.01 0.01 0.1
250 ~ 700 — 0.1 — — 0.1 — — 1 0.001 0.01 0.01 0.1
1000 — 1 — — 1 — — — 0.01 0.1 0.1 1
Load More Items

User Guide and Instruction manual for NAGMAN MPC-I-H+

You can request the necessary certificates, documentation, instructions and user guide for NAGMAN MPC-I-H+ using the special form.

You can buy NAGMAN MPC-I-H+ in Latvia at a favourable price in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email . NAGMAN MPC-I-H+ price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
