DWYER Durablock 420

Photo DWYER Durablock 420 Description DWYER Durablock 420 Ordering DWYER Durablock 420 Accessories for DWYER Durablock 420 Model Chart DWYER Durablock 420 User Manual for DWYER Durablock 420 Related instruments to DWYER Durablock 420

DWYER Durablock 420 inclined & vertical manometer

DWYER Durablock 420 inclined & vertical manometer
DWYER Durablock 420 inclined & vertical manometer

Dwyer® Series 420 Inclined-Vertical Manometer are extremely accurate instruments designed and made especially for precision measurement of low differential pressures in laboratory and test applications. The inclined range bore has a length of 20″ to provide ample multiplication of indicating fluid movement in this critical lower part of the range.

			int(2881)
NULL

Made in USA. brand DWYER, model Durablock 420

Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.

Retailprice from $1380,8

Available

Available

Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.

Advantages

Official distributor in Latvia

Time-tested American, European and Asian brands of control and measurent instruments

Advantages

Special price list for organisations

We offer a significant discount for trade organisations and manufacturing companies

Advantages

Worldwide shipping on request

We take care of all logistics and customs clearance. Fast delivery to Baltic countries

Advantages

After-sales service and support

Warranty service and repair, expert assistance in the operation of the instruments

Description of DWYER Durablock 420

NIST CALIBRATION available in Product Configurator.

PRODUCT APPLICATIONS

  • Low pressure laboratory and test applications

FEATURES

  • 1-1/4″ THICK ACRYLIC PLASTIC BODY is a solid block, virtually unbreakable, stable and absolutely free of the danger of distortion.
  • 3/16″ BORES, ACCURATE TO ± .0002″ are permanently free of bends or crooks, will not require recalibration because of distortion.
  • GROUND GLASS BUBBLE LEVEL sensitive to 115-125 sec./2 MM. is 1-1/2″ long x .375″ diameter and provided with two red lines for easy visibility and alignment.
  • PARALLAX-FREE READING for maximum accuracy and consistency is achieved by simply aligning the meniscus with its image reflected in the polished aluminum scale.
  • SELECTED GAGE FLUID with high wetability characteristics forms a consistent, well shaped meniscus for perfect readability.
  • O-RING SEALED FLUID LEVEL PLUNGER ADJUSTMENT for easy zeroing.
  • PRECISION BUILT to assure device meets the highest standards.

How to buy DWYER Durablock 420

Model Description Price
421-5 Inclined/vertical manometer, inclined range: 0-1.0″ w.c., .01 min. div., 6-1/2″ scale; vertical range 1.1-5″ w.c., min. div. .10, 4-5/8″ scale.
$1,380.80
421-10 Inclined/vertical manometer, inclined range: 0-1.0″ w.c., .01 min. div., 6-1/2″ scale; vertical range 1.1-10″ w.c., min. div. .10, 10-1/8″ scale.
$1,535.50
421-23 Inclined/vertical manometer, inclined range: 0-2.2″ w.c., .02 min. div., 6-1/8″ scale; vertical range 2.4-23″ w.c., min. div. .20, 10-1/4″ scale.
$1,957.70
422-5 Inclined/vertical manometer, inclined range: 0-1.0″ w.c., .01 min. div., 6-1/2″ scale; vertical range 1.1-5″ w.c., min. div. .10, 4-5/8″ scale.
$1,523.60
422-10 Inclined/vertical manometer, inclined range: 0-1.0″ w.c., .01 min. div., 6-1/2″ scale; vertical range 1.1-10″ w.c., min. div. .10, 10-1/8″ scale.
$1,804.40
422-23 Inclined/vertical manometer, inclined range: 0-2.2″ w.c., .02 min. div., 6-1/8″ scale; vertical range 2.4-23.0″ w.c., min. div. .20, 10-1/4″ scale.
$2,349.35
424-5 Inclined/vertical manometer, inclined range: 0-2.0″ w.c., .01 min. div., 20″ scale; vertical range 2.1-5″ w.c., min. div. .10, 3-1/4″ scale.
$2,266.15
424-10 Inclined/vertical manometer, inclined range: 0-2.0″ w.c., .01 min. div., 20″ scale; vertical range 2.1-10″ w.c., min. div. .10, 9″ scale.
$2,767.45
Load More Items

Accessories for DWYER Durablock 420

Model Description Price
A-101 1 oz dispenser bottle of red gage fluid, .826 sp. gr.
$10.85
A-102 4 oz bottle of red gage fluid, .826 sp. gr.
$21.15
A-103 1 pt bottle of red gage fluid, .826 sp. gr.
$46.95
A-104 1 qt bottle of red gage fluid, .826 sp. gr.
$88.25
A-110 1 oz dispenser bottle of blue gage fluid, 1.910 sp. gr.
$203.90
A-220 Clear flexible vinyl tubing, 3/16″ ID x 5/16″ OD, lengths to 500′; 45 psi maximum pressure @ 73°F.
$0.50
A-315 Gage connector, shutoff type, for 3/16″ rubber tubing.
$19.10
A-339 Adapter, brass, 1/8″ NPT to 3/16″ rubber and 1/8″ ID plastic tubing.
$5.55
Load More Items

Model Chart DWYER Durablock 420

SERIES 421

EXAMPLE 421 5 B Series 421-5-B Durablock® Inclined-Vertical Manometer, single column, 6-1/2″ inclined scale, range 0-1″ w.c. inclined and 1-5″ w.c. vertical, with type B connections.
SERIES 421 Single Column, 6-1/2″ Inclined Scale
RANGE 5
10
23
130MM
250MM
58CM		 0-1″ w.c. Inclined and 1-5″ w.c. Vertical
0-1″ w.c. Inclined and 1-10″ w.c. Vertical
0-2″ w.c. Inclined and 2-23″ w.c. Vertical
0-25 mm w.c. Inclined and 30-130 mm w.c. Vertical
0-25 mm w.c. Inclined and 30-250 mm w.c. Vertical
0-5.5 cm w.c. Inclined and 7-58 cm w.c. Vertical
OPTIONS B
C
D
E
AT
NIST		 Type B Connections
Type C Connections
Type D Connections
Type E Connections
Aluminum Tag
NIST Certificate of Calibration
Load More Items

SERIES 422

EXAMPLE 422 10 AT Series 422-10-AT Durablock® Inclined-Vertical Manometer, double column, 6-1/2″ inclined scale, range 0-1″ w.c. inclined and 1-10″ w.c. vertical, with aluminum tag.
SERIES 422 Double Column, 6-1/2″ Inclined Scale
RANGE 5
10
23
130MM
250MM
58CM		 0-1″ w.c. Inclined and 1-5″ w.c. Vertical
0-1″ w.c. Inclined and 1-10″ w.c. Vertical
0-2″ w.c. Inclined and 2-23″ w.c. Vertical
0-25 mm w.c. Inclined and 30-130 mm w.c. Vertical
0-25 mm w.c. Inclined and 30-250 mm w.c. Vertical
0-5.5 cm w.c. Inclined and 7-58 cm w.c. Vertical
OPTIONS B
C
D
E
AT
NIST		 Type B Connections
Type C Connections
Type D Connections
Type E Connections
Aluminum Tag
NIST Certificate of Calibration
Load More Items

User Guide and Instruction manual for DWYER Durablock 420

You can request the necessary certificates, documentation, instructions and user guide for DWYER Durablock 420 using the special form.

You can buy DWYER Durablock 420 in Latvia at a price starting from1380,8 $ in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email . DWYER Durablock 420 price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
