Temperature sensor suitable for measurement primarily in heat-treating furnaces, boiler houses, etc. This sensor has double protection tube: inner ceramic and outer made of heat resistant steel.
- Temperatura range: -40÷1200ºC R
- sensing element: S thermocouple
- connection head type AA IP53 – 40÷100ºC
- sheath material: steel 1.4762, 1.4841, and ceramic
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement primarily in heat-treating furnaces, boiler houses, etc. This sensor has ceramic protection tube.
- Temperatura range: 0÷1600ºC R
- ceramic tube: mullite 610 or corundum 799
- connection head type AA IP53, – 40÷100ºC
- sheath material: acid-resistant steel 1.4841, and ceramic
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement primarily in heat-treating furnaces, boiler houses, etc. This sensor has double ceramic protection tube.
- Temperatura range: -40÷1600ºC S
- sensing element: R thermocouple
- holding tube material, ceramic, mulit 610, corundum 799
- connection head type AA IP53 – 40÷100ºC
- sheath material: acid-resistant steel 1.4541 and ceramic
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement primarily in heat-treating furnaces, boiler houses, etc. This sensor has ceramic protection tube.
- Temperatura range: 0÷1600ºC R
- sensing element: R thermocouple
- ceramic sheath material: mullite 610, corundum 799
- connection head type BA IP55, – 40÷100ºC
- sheath material: acid-resistant steel 1.4541 and ceramic
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement of liquid glass. It has ceramic protection tube and additional platinum sheath. This sensor can be equipped with three thermocouples measuring temperature on different depths.
- Temperatura range: 0÷1600ºC R
- sensing element: R thermocouple
- ceramic tube material: corundum 799
- connection head type AA IP53, – 40÷100ºC
- sheath material: acid-resistant steel 1.4541 and ceramic
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement of liquid glass. It has ceramic protection tube and dusted platinum layer. This sensor can be equipped with three thermocouplesmeasuring temperature on different depths.
- Temperatura range: 0÷1600ºC R
- sensing element: R thermocouple
- ceramic tube material: corundum 799
- connection head type AA, IP53, -40÷150ºC
- protective coat material Pt, PtRh10, PtRh20
- temperature transmitter can be mounted in a connection head
price by request
Available
Temperature sensor suitable for measurement of liquid and gaseous media. It has a replaceable measuring insert adequate for various industrial applications. Replacement of the measuring insert does not cause the technological installation damage. Spring-loaded insert ensures an excellent connection with the bottom of the sensor thermowell. Temperature sensor has ATEX approval for application in hazardous area: II 2G Ex ia IIB T6 cable gland II 2GD Ex eb IIc, Ex ta IIIC (for the cable 5÷10mm)
- holding tube
- connection head type aluminium XE-DANA (S1-standard), XE-DAND (S2),
XE-DANAW (W1), XE-DANDW (W2) or stainless XE-BE (N1), IP65 - ceramic protection tube material: corundum 799
- cable gland ATEX II GD IP65 (for cable 5÷10 mm)
- Exi acc. to ATEX
price by request
Available
