The RD-24 is a remote input/output device that allows flexibility for applications needing more relays, analog outputs, or analog inputs. Using Modbus communication, you can control multiple I/O based on the application.
Made in USA. brand MACURCO, model RD-VRF
Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.
price by request
Available
Official distributor in Latvia
Time-tested American, European and Asian brands of control and measurent instruments
Special price list for organisations
We offer a significant discount for trade organisations and manufacturing companies
Worldwide shipping on request
We take care of all logistics and customs clearance. Fast delivery to Baltic countries
After-sales service and support
Warranty service and repair, expert assistance in the operation of the instruments
The RD-24 requires 24 VDC to operate and can be used to engage or disengage other equipment such as fans, louvers, horns, strobes, gas valves, etc. Using Modbus communication; you can control multiple I/O based on the application. The remote device can be wired in daisy-chain on the gas detector loop to save wire and allow for great mounting location flexibility.
Applications
Key features
| Size | 10.26″ x 11.06″ x 3.16″ (26.06 x 28.09 x 8.03 cm) |
| Weight | 2.8 lbs. (1.3 kg) |
| Voltage/Current | Power Input: 24VDC, 0.5A |
| Operating Temperature | 32 to 125°F (0 – 52°C) |
| Ambient Humidity | 0% – 95% RH non-condensing |
| Mounting | Mounting holes in each corner |
| Expansion Relay | 2 SDPT, 250VAC, 10A Max (resistive), max current draw 55mA |
| Expansion Analog Input | 4 Analog Inputs – max current draw 300mA |
| Expansion Analog Output | 2 Analog Outputs – max current draw 70mA |
| Settings | Dip Switch – 8 positions |
| Status Indicators | (LED): Power, communication, Slots 1-4 |
| Enclosure | NEMA4X rated |
| Warranty | Two year limited warranty |
You can request the necessary certificates, documentation, instructions and user guide for MACURCO RD-VRF using the special form.
You can buy MACURCO RD-VRF in Latvia at a favourable price in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email olil@olil.lv. MACURCO RD-VRF price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
