The Series ISDP Differential Pressure Transmitter provides a 4-20 mA process output, a robust NEMA 4X enclosure, plus a large LCD display that can be programmed to read in pressure, velocity or flow. The ISDP offers simplified programming via a Menu key that enables the user to select: security level; English or Metric engineering units; pressure, velocity or flow operation, K-factor for use with various Pitot tubes and flow sensors, circular or rectangular duct size for volumetric flow operation plus many more. The Series ISDP Differential Pressure Transmitter is powered on its two wire loop with 10-35 VDC via its integral M-12 four pin male connector. The ISDP provides a 0.5% full scale accuracy on ranges from 0.25″ w.c. to 100″ w.c. as well as bi-directional models up to 10″ w.c. These features make the Series ISDP Differential Pressure Transmitter the ideal instrument for monitoring pressures or air flows in hazardous zones having a Class I Div. I Groups A, B, C, D; Class II Div. I Groups E, F, G; Class III Div. I ratings.
price by request
Available
The Series 685 Differential Pressure Transmitter is used to measure differential pressure and vacuum. The adjustable pressure range and output signal make it the ideal choice for installers and maintenance professionals. It has a user-configurable response time via a jumper and can be mounted in any orientation. Applications include building automation systems, clean room monitoring, valve and flap control, filter monitoring, and air flow control. It has an adjustable pressure range, a single button to zero, and can be reset to factory settings with a long button press. No additional reference pressure sources or separate calibration devices are necessary.
price by request
Available
Intrinsically safe pressure transmitter, ATEX version
✔ Zones : 0, 1, 2, 20, 21, 22
✔ EMC emission and immunity: as per EN 61326.
✔ Case: with ventilation device.
✔ Calibration: adjustable.
price by request
Available
Differential Pressure (DP) is defined as the difference between two pressures. Differential Pressure Transmitters use a reference point called the low-side pressure and compare it to the high-side pressure. Ports in the instrument are marked high-side and low-side.
price by request
Available
The Series AT-MSX ATEX/IECEx Approved Magnesense® Differential Pressure Transmitter is an extremely versatile transmitter for monitoring pressure and air velocity in hazardous areas. This transmitter is loaded with features such as: field selectable English or metric ranges, field upgradeable LCD display, adjustable dampening of output signal and the ability to select a square root output for use with pitot tubes and other similar flow sensors. Along with these features, the piezo sensing technology provides long-term performance and enables the Magnesense® transmitter to be the solution for a myriad of pressure and flow applications. Flameproof enclosures are available in aluminum and can include a glass window for viewing process on the LCD.
price by request
Available
Intrinsically safe level transmitter, ATEX version
✔ Zones : 0, 1, 2
✔ EMC immunity: as per EN 61326.
price by request
Available
Differential Pressure (DP) is defined as the difference between two pressures. Differential Pressure Transmitters use a reference point called the low-side pressure and compare it to the high-side pressure. Ports in the instrument are marked high-side and low-side.
price by request
Available
The Series IDPT Industrial Differential Pressure Transmitter features a rugged, water resistant housing and highly stable accuracy for a long service life in most industrial applications. This pressure transmitter utilizes a capacitive pressure sensor on ranges 0 to 0.25 in w.c. to 0 to 1 in w.c. and a piezo sensor on ranges 0 to 2.5 in w.c. to 0 to 10 in w.c., both of which offer accuracy options of 0.25% or 0.5% full-scale. The cap cell allows the IDPT to maintain critical processes in industrial applications. The series offers a 4-20 mA 2-wire version for a loop powered current output as well as a 0-5 V/0-10 V selectable voltage output version.
price by request
Available
- SMART Transmitter 4-20mA + HART protocol
- Span limits : -1 to 100 bar
- Rangeability : 16:1
- Accuracy : 0.1%
- Power supply 10.5 to 45 VDC
- Process wetted parts material 316L stainless steel
- Process connection direct
- Burnout signal according NAMUR NE43 recommandations
- Long term stability : +/-0.1% of maximum span / 10years
Options: Local analog or digital Indicator; Intrinsically safe version; Explosion proof version; FM, CSA and IECEx certification; Stainless Steel electronic housing
price by request
Available
Flush diaphragm pressure transmitter, intrinsecally safe ATEX version
✔ Zones : mining, 0, 1, 2, 20, 21, 22
✔ Wetted parts: st.st.AISI 316L.
✔ EMC emission and immunity: as per EN 61326.
✔ Case: with ventilation device.
✔ Calibration: adjustable.
price by request
Available
- SMART Transmitter 4-20mA + HART protocol
- Span limits : 0 to 30 bar
- Rangeability : 16:1
- Accuracy : 0.2%
- Power supply 10.5 to 45VDC
- Process wetted parts material 316L stainless steel
- Process connection direct
- Burnout according NAMUR NE43 recommandations
- Long term stability : +/- 0.1% of maximum span / 10years
Options: Local analog or digital indicator, Intrinsically safe version, Explosion proof version, FM, CSA and IECEx certification, Stainless Steel electronic housing.
price by request
Available
Intrinsically safe pressure transmitter, for food industry and sanitary applications, ATEX version
✔ Construction and finishing: as per 74-06 SSI
✔ Zones : 0, 1, 2, 20, 21, 22
✔ Wetted parts: AISI 316L st.st.
✔ EMC emission and immunity: as per EN 61326
✔ Calibration: adjustable
✔ Full traceability
price by request
Available
- SMART Transmitter, 4-20mA + HART protocol
- Span limits : -1 to 500 bar
- Rangeability : 100:1
- Accuracy : 0.065% (0.04% as an option)
- Power supply : 10.5 to 45VDC
- Process wetted parts material : Inox 316L, Hastelloy, Monel, Tantalum, …
- Process connection : ¼”-18NPT (oval flanges on request)
- Burnout according NAMUR NE43 recommandations
- Long term stability : +/- 0.1% of maximum span / 10years
Options: Local analog or digital Indicator, Intrinsically safe version, Explosion proof version, FM, CSA and IECEX certification.
» Stainless Steel electronic housing
price by request
Available
