The TXP-FDE UV/IR detects fires and explosions extremely quickly allowing mitigation steps to be initiated more rapidly and limit event escalation.
Made in USA. brand MACURCO, model TXP-FDE UV/IR
Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.
price by request
Available
Official distributor in Latvia
Time-tested American, European and Asian brands of control and measurent instruments
Special price list for organisations
We offer a significant discount for trade organisations and manufacturing companies
Worldwide shipping on request
We take care of all logistics and customs clearance. Fast delivery to Baltic countries
After-sales service and support
Warranty service and repair, expert assistance in the operation of the instruments
The TXP-FDE UV/IR flame detector provides ultra-fast response, high performance and reliable detection of a large variety of fires including hydrocarbon fires (visible and non-visible), H 2 and CH 4 /H 2 mixed fires. The detector addresses slow growing fires and fast eruptions of fire using improved UV & IR technology operating in all weather and light conditions. The HD model provides high-definition color video of the monitored area with clear imaging of fire events and personnel at distances up to 100 ft. Video and event data are stored to non-volatile memory. Recordings start one minute before detection and continue for up to four minutes to assist with post incident investigation
Applications
Key features
| Dimensions | 5.51″ (L) x 3.54″ (W) x 3.54″ (H) |
| Shipping Weight | 9.9 lbs. (4.5 kg.) |
| Power & Electrical | Operating Voltage: 18-32 VDC Current (Standby): 120 mA Current (Maximum): 180 mA Conduit Entries: 2 x 3/4″ NPT or M25x1.5 Wiring: 12-20 AWG |
| Outputs | Relays: 3 x SPST 2A @ 30 VDC Analog: 4-20 mA stepped (sink or source) Digital: Modbus RS-485 RTU LED: Tri-color (Green, Yellow and Red) |
| HART | HART® 7 for configuration & maintenance |
| Detection Time and Distance | 5ms for fast burst of explosion For 1 sq. ft. (0.1 sq. m.) n-heptane pan fire: 1s at 0-50 ft. (0-15 m) <2s at 50-100 ft. (15-30 m) |
| Sensitivity Options | Extreme, High, Medium and Low |
| Field of View | 90° Horizontal and 80° Vertical |
| Time Delay | 0-30 seconds |
| Built-in-Test (BIT) | Automatic (Upon startup and in 20 minute intervals) Manual (PC software or wire terminal short) |
| Temperature Range | -67°F to +185°F (-55°C to +85°C) |
| Humidity | Up to 99% (RH), non-condensing |
| Ingress Protection | IP66 & 68 (2m, 24hr); NEMA 4X & 6P |
| Approvals | Refer to Table on Page 3 |
| 84-3211-1100-20 | TXP-FDE UV/IR, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-3211-1200-10 | TXP-FDE UV/IR, No Video, SS, M25, Tilt Mount |
| 84-4211-1200-10 | TXP-FDE UV/IR-F, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-4211-1100-20 | TXP-FDE UV/IR-F, No Video, SS, M25, Tilt Mount |
| 84-3112-1200-10 | TXP-FDE UV/IR-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-3112-1100-20 | TXP-FDE UV/IR-HD, Video, SS, M25, Tilt Mount |
| 84-4112-1200-10 | TXP-FDE UV/IR-F-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-4112-1100-20 | TXP-FDE UV/IR-F-HD, Video, SS, M25, Tilt Mount |
*Coordinates shown are for TXP-FDE UV/IR models only.
| Photo | Model | Description |
|---|---|---|
 |
84-3000-0000-08 | TXP-FDE UV/IR, SS, Flame Simulator Kit |
| 84-8000-0000-04 | TXP-FDE Weather Cover for Models without Video | |
| 84-8000-0000-05 | TXP-FDE USB to RS-485 PC Converter Kit | |
 |
84-8000-0000-08 | TXP-FDE Pole Mount Adapter, SS, 2″ & 3″ |
 |
84-8000-0000-01 | TXP-FDE HD Weather Cover |
| 84-8000-0000-10 | TXP-FDE HD Duct Mount Kit without Sapphire Window | |
| 84-8000-0000-11 | TXP-FDE HD Duct Mount Kit with Sapphire Window | |
| 84-8000-0000-12 | TXP-FDE HD Airshield for Dust and Snow Protection | |
| 84-8000-0000-13 | TXP-FDE HD Paint and Dust Shield Adapter Ring Kit | |
| 84-8000-0000-14 | TXP-FDE HD Disposable Paint and Dust Shields (Qty. 10) |
