Flame simulators are often used by industry to perform detector testing during commissioning and periodic system testing. The TXP-FDE simulators are inexpensive, lightweight and simple to use. The modern ergonomic design, with alignment markers, allows accurate, fast and convenient detector performance verification. Suitable for use in hazardous areas, the TXP-FDE flame simulators can be used at distances of up to 23 feet (7 meters) from the detector.
Made in USA. brand MACURCO, model TXP-FDE Simulator Kit
Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.
price by request
Available
Official distributor in Latvia
Time-tested American, European and Asian brands of control and measurent instruments
Special price list for organisations
We offer a significant discount for trade organisations and manufacturing companies
Worldwide shipping on request
We take care of all logistics and customs clearance. Fast delivery to Baltic countries
After-sales service and support
Warranty service and repair, expert assistance in the operation of the instruments
The TXP-FDE Flame Simulator provides fast and convenient detector verification in the field.
Three different models are available for testing each type of TXP-FDE Flame Detector (IR3, IR3-H2 and UV-IR).
All TXP-FDE flame detectors perform automatic self-tests of their optics, windows, electronics and software. Additionally, the TXP-FDE flame detectors can be manually put into alarm via the PC communicator software or by short circuiting the “Manual BIT” terminal and the “24 VDC (-)“ terminal for one second. The TXP-FDE flame test simulators are designed to complement these inbuilt features by providing a fully external loop test capability.
Applications
Key features
| Simulator Kit Part Numbers | TXP-FDE IR3 Kit | TXP-FDE IR3-H2 Kit | TXP-FDE UV/IR Kit | |
| Detector Type | TXP-FDE IR3 | TXP-FDE IR3-H2 | TXP-FDE UV/IR | |
| TXP-FDE IR3-HD | TXP-FDE IR3-H2-HD | TXP-FDE UV/IR-HD | ||
| Operation Distances | Detector Sensitivity | ft. m | ft. m | ft. m |
| Extreme | 23.0 7.0 | 23.0 7.0 | 21.3 6.5 | |
| High | 16.0 5.0 | 16.0 5.0 | 16.0 5.0 | |
| Medium | 10.0 3.0 | 10.0 3.0 | 13.0 4.0 | |
| Low | 3.3 1.0 | 3.3 1.0 | 3.3 1.0 | |
| Electrical Specifications | Operating Voltage nominal, V | 3.7 | 3.7 | 3.7 |
| Number of Activations between charging | ~1000 | ~1000 | ~50 | |
| Battery Capacity, mAh | >3000 | >3000 | >3000 | |
| Charging time, hours | up to 3 | up to 3 | up to 3 | |
| Indication | 3 color LED (Green, Yellow, Red) | |||
| All Simulator Models | ||||
| Mechanical Specifications | Size | 3.9 x 3.9 x 7.8″ (100 x 100 x 200mm) | ||
| Weight | 3.96 lbs. (1.8 kg) | |||
| Simulator Enclosure Material | Painted Aluminum LM25 | |||
| Environmental Specifications | Ingress Protection | IP65 (NEMA 4X) | ||
| Humidity | up to 99% (RH), non-condensing | |||
| Operating temperature | Min: -4°F (-20°C) Max: +122°F (+50°C) | |||
| Approvals | Explosion proof | ATEX Ex II 2 G Ex db ib op is IIC T6 Gb Ex II 2 D Ex tb ib op is IIIC T85°C Db -20°C<Ta<+50°C | ||
| Included in Kits | Carrying case, carrying strap, cover tool, allen key, battery charger and spare battery | |||
| Warranty | 3 Years | |||
You can request the necessary certificates, documentation, instructions and user guide for MACURCO TXP-FDE Simulator Kit using the special form.
You can buy MACURCO TXP-FDE Simulator Kit in Latvia at a favourable price in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email olil@olil.lv. MACURCO TXP-FDE Simulator Kit price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
