The Macurco RD-VRF Refrigerant Gas Detector is designed to provide continuous refrigerant monitoring in VRF (Variable Refrigerant Flow) applications as well as other similar applications. The RD-VRF Refrigerant Gas Detector comes standard with 2 alarm levels providing advanced warning via low detection alarming and notification to activate two onboard relays that can be used to control valves to isolate or shutdown refrigerant supply lines, engage exhaust fans, provide notification alarms, and communicate to a Building Management System (BMS). The RD-VRF comes standard with Modbus RS-485 and optional BACnet communication.
Made in USA. brand MACURCO, model RD-VRF
Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.
price by request
Available
Official distributor in Latvia
Time-tested American, European and Asian brands of control and measurent instruments
Special price list for organisations
We offer a significant discount for trade organisations and manufacturing companies
Worldwide shipping on request
We take care of all logistics and customs clearance. Fast delivery to Baltic countries
After-sales service and support
Warranty service and repair, expert assistance in the operation of the instruments
The Macurco RD-VRF Refrigerant Gas Detector is designed to provide continuous refrigerant monitoring in VRF (Variable Refrigerant Flow) applications. Depending on the type of refrigerant, a leak in refrigerant gas could develop an oxygen depleting environment that may lead to asphyxiation or combustible refrigerant may lead to an explosion. The RD-VRF Refrigerant Gas Detector comes standard with 2 alarm levels providing advanced warning via low detection alarming and notification locally or via a Building Management System (BMS)
Key features
Applications
| Size | 5.157″(H) x 5.088″(W) x 1.861″(D) |
| Shipping Weight | 0.5 lb. (8 oz.) |
| Voltage/Current | 3W (max) from 14 to 24VDC or 14 to 32VAC 4.3W (max at 120VAC), 50 to 60 Hz |
| Current Draw | 24V 48mA normal / 74mA full alarm 120VAC: 21mA normal and 36mA alarm |
| Alarm Levels | 1,000 & 2,000PPM, 10% & 20% LEL |
| Signal | RS485 serial output |
| Relays | 2 SPDT relays @ 2.0A at 30VDC |
| Buzzer Rating | 75 dBA at 10 Ft |
| Visual Indicator | RGB LED |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Ambient Humidity | 0-95% RH non-condensing |
| Warranty | Two year limited warranty |
| Life Expectancy | 10 years with EOL notification |
| Certifications | REACH/RoHS |
| Panel Compatibility | DVP-1200 Series |
Series:
RD-VRF – Refrigerant Monito
Gas Type:
R-32 – Range: 0-10,000 PPM/0-100% LEL; Resolution: 50 PPM/1% LEL
R-134a – Range: 0-5,000 PPM; Resolution: 25 PPM
R-404A – Range: 0-5,000 PPM; Resolution: 25 PPM
R-407C – Range: 0-5,000 PPM; Resolution: 25 PPM
R-410A – Range: 0-10,000 PPM; Resolution: 50 PPM
R-449A – Range: 0-5,000 PPM; Resolution: 25 PPM
R-452B – Range: 0-100% LEL; Resolution: 1% LEL
R-454A – Range: 0-100% LEL; Resolution: 1% LEL
R-454B – Range: 0-100% LEL; Resolution: 1% LEL
R-454C – Range: 0-100% LEL; Resolution: 1% LEL
R-455A – Range: 0-100% LEL; Resolution: 1% LEL
R-1234yf – Range: 0-5,000 PPM/0-100% LEL; Resolution: 25 PPM/1% LEL
R-1234ze – Range: 0-5,000 PPM/0-100% LEL; Resolution: 25 PPM/1% LEL
Unit of Measure
PPM = Parts Per Million
LEL = % LEL (Lower Explosive Limit)
Digital Output
M = Modbus (standard)
You can request the necessary certificates, documentation, instructions and user guide for MACURCO RD-VRF using the special form.
