DWYER RSF

Photo DWYER RSF Description DWYER RSF Specifications DWYER RSF Ordering DWYER RSF Accessories for DWYER RSF User Manual for DWYER RSF Related instruments to DWYER RSF

DWYER RSF rotatable scale flowmeter

DWYER RSF rotatable scale flowmeter
DWYER RSF rotatable scale flowmeter

The Series RSF Rotatable Scale Flowmeters are ideal for the direct flow measurement of air, water, and other commonly used gases. These flowmeters are designed with direct read scales with no need for correlation charts and graduations are marked on a rotating, polycarbonate tube shield. They feature borosilicate glass tubes with brass and SS metering valve options.

			int(5950)
NULL

Made in USA. brand DWYER, model RSF

Fast delivery to Latvia, Estonia and Lithuania. International delivery to Europe, Asia, Africa and other continents available on request
Our warehouse is located in Riga, Latvia.

Retailprice from $934,6

Available

Available

Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.

Advantages

Official distributor in Latvia

Time-tested American, European and Asian brands of control and measurent instruments

Advantages

Special price list for organisations

We offer a significant discount for trade organisations and manufacturing companies

Advantages

Worldwide shipping on request

We take care of all logistics and customs clearance. Fast delivery to Baltic countries

Advantages

After-sales service and support

Warranty service and repair, expert assistance in the operation of the instruments

Description of DWYER RSF

Calibration Options are available in the Accessory tab. For PTFE Models contact the factory.

PRODUCT APPLICATIONS

  • Water and air pollution analysis equipment
  • Water and air pollution analysis systems

FEATURES

  • Reflective lens background and 1.5 X magnification lens reduces parallax and eye fatigue saving time and allowing for a more accurate reading
  • Long operating life with thick polycarbonate front shield that protects tube from breakage and serves as a magnifying lens to enhance reading resolution
  • Increased protection with included safety blow-out back panel for added safety in the event of breakage

Technical specifications of DWYER RSF

  • Service: Compatible gases or liquids.
  • Wetted Materials: Flowtube: Borosilicate glass; Float: Brass/SS models: 316 SS; PTFE models: PTFE; Float stops: Brass/SS models: 316 SS; PTFE models: PTFE; End fittings: Brass/SS models: Brass or 316 SS; PTFE models: PTFE; O-rings: Brass/SS models: Fluoroelastomer; PTFE models: PTFE.
  • Temperature Limits: 250°F (121°C). PTFE models: 150°F (65°C).
  • Pressure Limits: 150 psig (10.34 bar) @ 200°F (93°C); PTFE models: 100 psig (6.7 bar).
  • Accuracy: ±7% FS.
  • Repeatability: ±0.25% FS.
  • Scale: Direct Reading 127 mm scales for air and water.
  • Turn-Down Ratio: 10:01
  • Connections: Two 3/8″ female NPT.
  • Mounting: Vertical or panel mount.
  • Panel Cutout: Drill two 7/8″ diameter holes 9.469″ (240.5 mm) apart (for panel mount meters only).
  • Valve: 6-turn needle (standard on models indicating “with valve”).

How to buy DWYER RSF

Model Description Price
RSF011 Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$934.60
RSF011V Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,073.30
RSF012 Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$934.60
RSF012V Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,073.30
RSF013 Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$934.60
RSF013V Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,073.30
RSF014 Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$934.60
RSF014V Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,073.30
RSF015 Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$934.60
RSF015V Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,073.30
RSF021 Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$934.60
RSF021V Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,073.30
RSF022 Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$934.60
RSF022V Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,073.30
RSF023 Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$934.60
RSF023V Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,073.30
RSF024 Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$934.60
RSF024V Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,073.30
RSF025 Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$934.60
RSF025V Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,073.30
RSF111 Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,362.05
RSF111V Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,586.65
RSF112 Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,362.05
RSF112V Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,586.65
RSF113 Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,362.05
RSF113V Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,586.65
RSF114 Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,362.05
RSF114V Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,586.65
RSF115 Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,362.05
RSF115V Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,586.65
RSF121 Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,362.05
RSF121V Rotatable scale flowmeter, max. flow rate 5 SCFM (140 SLPM) air, 1.2 GPM (4 LPM) water.
$1,583.55
RSF122 Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,362.05
RSF122V Rotatable scale flowmeter, max. flow rate 10 SCFM (280 SLPM) air, 2 GPM (8 LPM) water.
$1,583.55
RSF123 Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,362.05
RSF123V Rotatable scale flowmeter, max. flow rate 15 SCFM (425 SLPM) air, 3 GPM (11.5 LPM) water.
$1,583.55
RSF124 Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,362.05
RSF124V Rotatable scale flowmeter, max. flow rate 20 SCFM (575 SLPM) air, 4 GPM (15 LPM) water.
$1,583.55
RSF125 Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,362.05
RSF125V Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
$1,583.55
Load More Items

Accessories for DWYER RSF

Model Description Price
NISTCAL-FL1 NIST traceable calibration certificate for variable area flowmeters (air).
NOTE: EQUAL CERTS WILL BE CHARGED PER UNITS PURCHASED.
$352.00
NISTCAL-FL2 NIST traceable calibration certificate for variable area flowmeters (water).
NOTE: EQUAL CERTS WILL BE CHARGED PER UNITS PURCHASED.
$292.00
Load More Items

User Guide and Instruction manual for DWYER RSF

You can request the necessary certificates, documentation, instructions and user guide for DWYER RSF using the special form.

You can buy DWYER RSF in Latvia at a price starting from934,6 $ in «OLIL SIA» by leaving a request on the website, by phone +371 672 70580 or by email . DWYER RSF price are subject to change depending on exchange rates. We deliver instruments by transport companies in Latvia, Estonia and Lithuania. Worldwide shipping to Europe, Asia, Africa, North and South America available on request.
